BlueFusion Folding Solar Panel 50W 100W 120W, 12V/24V Lithium Battery Solar Charger

Flex Power Portable Solar Panels 50W, 100W, 120W

• A quality product, designed to be portable and withstand outdoor environments.
• Manufactured from High Efficiency A Grade Mono Cells. 20 Year Power Output Warranty***
• Solar Charger for 12V/24V Battery. 2m Battery cable with fuse and alligator clamps.
• Compatible with 12V/24V GEL, Lead Acid and Lithium Batteries.
• Folding solar panels, suitable for off-grid charging of 12V/24V batteries for Caravans & RV, Camping and Hiking Equipment, Electric Outboard Trolling Motor, and Residential use.
• Excellent low light capabilities. High conversion efficiency.

Lightweight and Portable, Integrated DC Charge Controller

• Integrated Charge Controller, concealed inside the panel.
• 12V/24V and 5V USB DC Output:
  • Charge 12V or 24V Battery. 2m Battery cable, fused and alligator clamps.
  • Charge Phones and Devices from USB socket, 5V, 1.2 Amp.  An external 12V battery is required to operate USB Charger. Battery not included.

Electrical Characteristics

Panel Specification

How to Configure (Program) Solar Controller for Lithium Batteries

• The default charging voltage of the controller is factory set for Sealed Lead Acid Batteries.
• Lithium Batteris come in various chemistries and voltage. Consult the Lithium Battery manufacturer and set correct voltages in the controller to ensure safe and efficient charging of the battery.
• Detailed instructions are in the box. Follow these steps to set up your Lithium Battery:

1. Set custom battery type to b00 (Lithium Battery)
2. Set the Maximum charge voltage of the Lithium Battery. This is the ‘Float Charge Voltage’ or HVD (High Voltage Disconnect). Configurable Range: 12.9V – 15V (for 12V system). 25.5V – 30V (for 24V system).
3. Set the ‘Under Voltage Protection’ of the Lithium Battery. This is the LVD (Low Voltage Disconnect) and prevents load from operating when battery is discharged. Configurable Range: 9V – 12V (for 12V system). 18V – 24.9V (for 24V system)
4. Optionally set the ‘Recovery after Undervoltage’ value. This is the voltage above which the load will reconnect after undervoltage protection is triggered. Range 9.3V – 12.3V (for 12V system). This value must be higher than ‘Under Voltage Protection’ value.

Solar Panel Linear Power Warranty***

• • 20 Year, 80% power output warranty
  • 1 Year limited product warranty

Precaution: Solar panels produce electricity and can lead to electrical shock and injury. All electrical connections should be carried out by a competent adult.

Note: Specification subject to change, manufacturing tolerance and product improvement. Can withstand some drizzle, protect from substantial rain.
